Engine
|
forward mounted 4 cylinder four stroke, in-line (OHV)
|
|
Crankshaft
|
five main bearings
|
|
Capacity
|
1298 cc (79.2 cu in)
|
|
Bore x Stroke
|
80,98 x 62,99 mm (3.19in x 2.48in)
|
|
Compression ratio
|
9 : 1
|
|
Maximum power
|
52 bhp @ 5000 rpm (from 1970: 57 bhp @ 5700 rpm)
|
|
Maximum torque
|
(mkp - U/min) 66 lb.ft@2500 rpm (from 1970: 66 lb.ft@3000
rpm)
|
|
Valve gear
|
overhead valves; push rods and rockers.
|
|
Fuel system / carburation
|
single downdraught carburettor. Motorcraft GPD
|
|
Type of fuel
|
Min octane 4 star 97RM
|
|
Fuel capacity
|
48 liters = UK Gal. 10.558 (84.462 pint)
|
|
Lubrication
|
force-feed lubrication system with oil filter in the main
oil line
|
|
Oil capacity
|
3.5 liters - with filter 4,0 liters (0.769 / 0.879 UK Gal.)
|
|
Cooling system capacity
|
1.275 UK Gal. (10,205 pint) = 5,8 liters including heater
|
|
Car battery
|
12 V - 38 Ah
|
|
Generator
|
dynamo / 14 V - 25 A
|
|
Transmission / Gear ratios
|
four-speed manuel gearbox, fully synchronized:
1st. 3,54 - 2nd 2,40 - 3rd 1,41 - 4th 1,0 - rev. 3,96
|
|
Final drive ratio
|
4,125 (optional 4,444)
|
|
Powertrain
|
one-piece drive shaft
|
|
Construction
|
steel monocoque
|
|
Front axle
|
independent coil springs with telescopic dampers, macPherson
struts and anti-roll bar.
|
|
Rear axle
|
live axle half elliptic leaf springs, twin radius arms and
telescopic dampers.
|
|
Steering system
|
Rack and pinion steering linkage, safety steering wheel.
Rate of transmission 17,7: 1
|
|
Turning circle
|
31.82ft (9.7 m)
|
|
Tyres
|
cross ply 6 x 13in or 165SR x 13
|
|
Wheels
|
steel disc weels 4,5 x 13in; optional Ro-Style wheels 5,5
and 165/30 tyres (5 x 13in standard from Sept. 72)
|
|
Brake system
|
Hydraulic dual circuit brake system. Disc brakes at the front
and drum brakes at the rear. Mechanical hand brake on the
rear wheels.
Brakes servo optional
Disc: 9.586in x 0,381in = 243,5 mm x 9,7 mm
brake drum: 7.992in x 1,5in = 203 x 38,1 mm
brake-shoe:
Width x Gage x Length: 1,49in x 0.188in x 6,299in = 38 x 4,8
x 160 mm
|
|
Length x Width x Height
|
169,4 x 64,7 x 52,3in = 4303 x 1645 x 1330 mm
|
|
Front track / Rear track
|
53in (1346mm) / 52in (1320mm) Wheelbase: 100.8in
(2559mm)
|
|
Luggage boot
|
ca. 355 liters
|
|
Curb weigth
|
1940 pound (880 kg)
|
|
Gross weight
|
2854 pound (1295 kg)
|
|
0 - 62mph
|
23,0 secs (from 1970: 22,0 secs)
|
|
Maximum speed
|
84 mph = 135 km/h (from 1970: 86 mph = 138 km/h)
|
|
Fuel consumption
|
30,989 (mpg) = 100 km / 9,1 litre
|
