engine
|
forward mounted 4 cylinder four stroke, in-line (OHC)
|
|
crankshaft
|
five main bearings
|
|
Capacity
|
1993 cc (121.6 cu in)
|
|
bore x stroke
|
90,8 x 76,9 mm (3.57in x 3.03in)
|
|
compression ratio
|
8,6 : 1 (8,2 : 1 in 1971)
|
|
maximum power
|
100 bhp SAE @ 5600 rpm (86 bhp DIN @ 5400 rpm in 1972 -
85bhp DIN @ 5600 rpm in 1973 - 80bhp DIN @ 5400 rpm in 1974)
|
|
maximum torque
|
(mkp - U/min) 120lb.ft SAE @3600 rpm - 98lb.ft SAE @3000
rpm in 1974
|
|
valve gear
|
overhead camshaft
|
|
Fuel system / carburation
|
Twin-choke carburettor
|
|
type of fuel
|
gas super
|
|
fuel capacity
|
48 liters = UK Gal. 10.558 (84.462 pint)
|
|
lubrication
|
force-feed lubrication system with oil filter in the main
oil line
|
|
oil capacity
|
3.25 liters - with filter 3,75 liters (0.714 / 0.824 UK Gal.)
|
|
cooling system capacity
|
1.319 UK Gal. (10,557 pint) = 6,0 liters including heater
|
|
car battery
|
12 V - 44 A
|
|
generator
|
dynamo / 14 V - 28
|
|
gearbox
|
four-speed synchromesh transmission:
I. 3,65 - II. 1,97 - III. 1,37 - IV. 1,0 - R. 3,66
Optional Borgwarner 35 three-speed automatic
|
|
final drive ratio
|
3.44
|
|
powertrain
|
one-piece drive shaft
|
|
construction
|
steel monocoque
|
|
front axle
|
independent coil springs with telescopic dampers, macPherson
struts and anti-roll bar.
|
|
rear axle
|
live axle half elliptic leaf springs, twin radius arms and
telescopic dampers.
|
|
steering system
|
Rack and pinion steering linkage, safety steering wheel.
Rate of transmission 17,7: 1
|
|
turning circle
|
32.15ft (9.80 m)
|
|
tyres
|
radial-ply 165 x 13
|
|
wheels
|
steel disc weels 5 x 13in
|
|
brake system
|
Hydraulic dual circuit brake system. Disc brakes at the front
and drum brakes at the rear. Mechanical hand brake on the
rear wheels. Brakes standard Servo.
Disc: 9.606in x 0,503in = 244 mm x 12,8 mm
Drum x Width: 8in x 1,496in = 203,2 mm x 45mm
brake-shoe:
Width x gage x Length: 1,73in x 0,188in x 7,086in = 44 x 4,8
x 180 mm
|
|
length x width x height
|
167.8 x 64.8 x 52.3in = 4262 x 1646 x 1330 mm (173,8in -
4415mm 1973)
|
|
Front Track / Rear Track
|
53in (1346mm) / 52in (1321mm) Wheelbase 100,8in
(2559mm)
|
|
Luggage boot
|
ca. 355 liters
|
|
curb weigth
|
2208 pound (1002 kg)
|
|
gross weight
|
2943 pound (1335 kg)
|
|
0 - 62mph
|
11,5 sec. (13,5 sec. from 1972)
|
|
maximum speed
|
108 mph = 174 km/h (100 mph = 161 km/h from 1972)
|
|
fuel consumption
|
24.955 (mpg) = 100 km / 11,3 litre
|
